UV Broadband photodiodes,

different packagings and detector areas. Please scroll down for selective UV photodiodes (UVA, UVB, UVC, Erythema).

--------------------------------------------

spectral curve

0.06 mm² detector area,

TO18 housing

product picture

0.06 mm² detector area,

flat TO18 housing

product picture

0.06 mm2 detector area,

TO18 housing, two isolated pins, one additional grounded pin

product picture

0.06 mm2 detector area,

flat TO5 housing

product picture

0.2 mm² detector area,

TO18 housing

product picture

0.2 mm² detector area,

flat TO18 housing

product picture

0.2 mm² detector area,

TO18 housing, two isolated pins, one additional grounded pin

product picture

0.2 mm² detector area,

according to EN298 standard (flame detecton), TO5 housing with concentrating lens (11 mm² virtual detector area)

product picture

0.5 mm² detector area,

TO18 housing

product picture

0.5 mm² detector area,

according to EN298 standard (flame detecton), TO5 housing with concentrating lens (11 mm² virtual detector area)

product picture

1.00 mm² detector area,

TO18 housing

product picture

1.00 mm² detector area,

flat TO18 housing

product picture

1.00 mm² detector area,

TO18 housing, two isolated pins, one additional grounded pin

product picture

1.00 mm² detector area,

flat TO5 housing

product picture

4.00 mm² detector area,

TO5 housing

product picture

4.00 mm² detector area,

flat TO5 housing, two isolated pins, one additional grounded pin

product picture

--------------------------------------------

UVA photodiodes,

different packagings and detector areas. Please scroll down for other selective UV photodiodes (UVB, UVC, Erythema).

--------------------------------------------

spectral curve

0.06 mm² detector area,

TO18 housing

product picture

0.2 mm² detector area,

TO18 housing

product picture

0.2 mm² detector area,

TO5 housing

product picture

0.5 mm² detector area,

TO18 housing

product picture

1.00 mm² detector area,

TO5 housing

product picture

1.00 mm² detector area,

TO18 housing

product picture

4.00 mm² detector area,

TO5 housing

product picture

--------------------------------------------

UVB photodiodes,

different packagings and detector areas. Please scroll down for other selective UV photodiodes (UVC, Erythema).

--------------------------------------------

spectral curve

0.06 mm² detector area,

TO18 housing

product picture

0.2 mm² detector area,

TO18 housing

product picture

0.2 mm² detector area,

TO5 housing

product picture

0.5 mm² detector area,

TO18 housing

product picture

1.00 mm² detector area,

TO5 housing

product picture

1.00 mm² detector area,

TO18 housing

product picture

4.00 mm² detector area,

TO5 housing

product picture

--------------------------------------------

UVC photodiodes according to DVGW W294(2006)

different packagings and detector areas. Please scroll down for other selective UV photodiodes (Erythema).

--------------------------------------------

spectral curve

0.06 mm² detector area,

TO18 housing

product picture

0.06 mm² detector area,

TO5 housing

product picture

0.2 mm² detector area,

TO5 housing

product picture

0.5 mm² detector area,

TO18 housing

product picture

1.00 mm² detector area,

TO5 housing

product picture

1.00 mm² detector area,

TO18 housing

product picture

4.00 mm² detector area,

TO5 housing

product picture

--------------------------------------------

UV-Index photodiodes according to CIE087

3% error only = most precise currently available detector, cosine corrected, different active areas

--------------------------------------------

spectral curve

0.2 mm² detector area,

TO18 housing

product picture

0.5 mm² detector area,

TO18 housing

product picture

1.00 mm² detector area,

TO5 housing, cosine corrected

product picture

4.00 mm² detector area,

TO5 housing, cosine corrected

product picture

--------------------------------------------

UV Broadband=type "TOCON_ABC"

below list arranges the sensors by decreasing sensitivity from "ABC1"=very sensitive to "ABC10"=very unsensitive. Please scroll down for selective TOCONs (UVA, UVB, UVC, Erythema, blue light).

--------------------------------------------

spectral curve

approx. 1.8 pW/cm² ... 18 nW/cm²

Replaces obsolete UV10.SF and UV10.T2E

flame detection

approx. 18 pW/cm² ... 180 nW/cm²

approx. 180 pW/cm² ... 1.8 µW/cm²

approx. 1.8 nW/cm² ... 18 µW/cm²

approx. 18 nW/cm² ... 180 µW/cm²

approx. 180 nW/cm² ... 1.8 mW/cm²

measurement of the sun's total UV radiation

For measurement of the erythemal part of the sun UV the TOCON_E2 is applied.

approx. 1.8 µW/cm² ... 18 mW/cm²

approx. 18 µW/cm² ... 180 mW/cm²

approx. 180 µW/cm² ... 1.8 W/cm²

curing lamp control

approx. 1.8 mW/cm² ... 18 W/cm²

UV hardening control and other very high radiation sources

--------------------------------------------

UVA = type "TOCON_A"

below list arranges the sensors by decreasing sensitivity from "A4"=very sensitive to "A10"=very unsensitive. Please scroll down for other selective TOCONs (UVB, UVC, Erythema, blue light).

--------------------------------------------

spectral curve

(old part no. TOCON_A3 until 31 March 2014)

approx. 1.8 nW/cm² ... 18 µW/cm²

(old part no. TOCON_A4 until 31 March 2014)

approx. 18 nW/cm² ... 180 µW/cm²

(old part no. TOCON_A5 until 31 March 2014)

approx. 180 nW/cm² ... 1.8 mW/cm²

(old part no. TOCON_A6 until 31 March 2014)

approx. 1.8 µW/cm² ... 18 mW/cm²

(old part no. TOCON_A7 until 31 March 2014)

approx. 18 µW/cm² ... 180 mW/cm²

(old part no. TOCON_A8 until 31 March 2014)

approx. 180 µW/cm² ... 1.8 W/cm²

(old part no. TOCON_A9 until 31 March 2014)

approx. 1.8 mW/cm² ... 18 W/cm²

UVA hardening lamp control

--------------------------------------------

UVB = type "TOCON_B"

below list arranges the sensors by decreasing sensitivity from "B4"=very sensitive to "B6"=very unsensitive. Please scroll down for other selective TOCONs (UVC, Erythema, blue light).

--------------------------------------------

spectral curve

(old part no. TOCON_B1 until 31 March 2014)

max. 7.5 µW/cm²

(old part no. TOCON_B2 until 31 March 2014)

max. 75 µW/cm²

(old part no. TOCON_B3 until 31 March 2014)

max. 0.75 mW/cm²

--------------------------------------------

UVC = type "TOCON_C"

below list arranges the sensors by decreasing sensitivity from "C2"=very sensitive to "C9"=very unsensitive. Please scroll down for other selective TOCONs (Erythema, blue light).

--------------------------------------------

spectral curve

approx. 18 pW/cm² ... 180 nW/cm²

approx. 180 pW/cm² ... 1.8 µW/cm²

approx. 1.8 nW/cm² ... 18 µW/cm²

approx. 18 nW/cm² ... 180 µW/cm²

approx. 180 nW/cm² ... 1.8 mW/cm²

purification lamp control

approx. 1.8 µW/cm² ... 18 mW/cm²

approx. 18 µW/cm² ... 180 mW/cm²

approx. 180 µW/cm² ... 1.8 W/cm²

--------------------------------------------

UV-Index = type "TOCON_E"

below list arranges the sensors by decreasing sensitivity from "E1"=very sensitive to "E2"= unsensitive. Please scroll down for other selective TOCONs (blue light).

--------------------------------------------

spectral curve

approx. 3 UVI

approx. 30 UVI

UV-Index measurements according to CIE087,

<3% error, cosine corrected

UV-Index measurements according to CIE087, <3% error,

designed to work with customers cosine correcting dome

--------------------------------------------

Blue light = type "TOCON_Blue"

below list arranges the sensors by decreasing sensitivity from "blue4"=very sensitive to "blue9"=very unsensitive.

--------------------------------------------

spectral curve

(old part no. TOCON_blue1 until 31 March 2014)

approx. 4.2 nW/cm² ... 43 µW/cm²

(old part no. TOCON_blue2 until 31 March 2014)

approx. 42 nW/cm² ... 430 µW/cm²

measurement of blue light (approx. 400...500nm) according to guideline 2006/25/EG (Limits on exposure to artificial optical radiation.)

(old part no. TOCON_blue3 until 31 March 2014)

approx. 420 nW/cm² ... 4.3 mW/cm²

(old part no. TOCON_blue4 until 31 March 2014)

approx. 4.2 µW/cm² ... 43 mW/cm²

(old part no. TOCON_blue5 until 31 March 2014)

approx. 42 µW/cm² ... 430 mW/cm²

(old part no. TOCON_blue6 until 31 March 2014)

approx. 420 µW/cm² ... 4.3 W/cm²

--------------------------------------------

GaP = type "TOCON_GaP"

below list arranges the sensors by decreasing sensitivity from "GaP4"=very sensitive to "GaP9"=very unsensitive.

--------------------------------------------

 spectral curve

(old part no. TOCON_GaP1 until 31 March 2014)

approx. 4.2 nW/cm² ... 43 µW/cm²

(old part no. TOCON_GaP2 until 31 March 2014)

approx. 42 nW/cm² ... 430 µW/cm²

(old part no. TOCON_GaP3 until 31 March 2014)

approx. 420 nW/cm² ... 4.3 mW/cm²

(old part no. TOCON_GaP4 until 31 March 2014)

approx. 4.2 µW/cm² ... 43 mW/cm²

(old part no. TOCON_GaP5 until 31 March 2014)

approx. 42 µW/cm² ... 430 mW/cm²

(old part no. TOCON_GaP6 until 31 March 2014)

approx. 420 µW/cm² ... 4.3 W/cm²

--------------------------------------------

TOCON housing

--------------------------------------------

optional probe housing for every TOCON with integrated sensor connector for easy mounting.

M12x1 thread, 32 mm length, integrated sensor connector, price incl. 2 m plug cable.

product picture

M12x1 thread, material teflon (PTFE), 31 mm length, integrated sensor connector, price incl. 2 m plug cable.

product picture

Kit for initial testing setup

product picture

------------------------------------------------------------------

PLEASE SELECT A MECHANICAL DESIGN

------------------------------------------------------------------

Standard surface-mount 180^o FOV UV Sensor

product picture

Waterproof UV Sensor for outdoor use

product picture

Axis oriented in-chamber UV Sensor

product picture

10 bar water pressure proof UV sensor

for low pressure lamps

product picture

10 bar water pressure proof UV sensor with G3/4" thread

for medium and low pressure lamps

product picture

UV Sensor for DVGW certified water purifiers

minimum order quantity 15 pieces

product picture

UV Sensor for DVGW (160°) and OE-Norm certified water purifiers

minimum order quantity 15 pieces

product picture

Amplified UV Photodetector with housing

product picture

Sensor for hard UV irradiation with integrated temperature sensor

can be used permanently up to 170°C (338°F)

product picture

------------------------------------------------------------------

PLEASE SELECT A SPECTRAL SENSITIVITY

------------------------------------------------------------------

configure the sensor with an UV broadband SiC detector

spectral sensitivity

configure the sensor with an UVA-only SiC detector

spectral sensitivity

configure the sensor with an UVB-only/UV-Index SiC detector

spectral sensitivity

configure the sensor with an UVC-only SiC detector

spectral sensitivity

------------------------------------------------------------------

PLEASE SELECT A SIGNAL OUTPUT

------------------------------------------------------------------

------------------------------------------------------------------

PLEASE SELECT A SIGNAL OUTPUT

------------------------------------------------------------------

configure the sensor with a 0...5 V signal output

configure the sensor with a 4...20 mA signal output

configure the sensor with an USB signal output

configure the sensor with an adjustable level output for flash measurements

------------------------------------------------------------------

PLEASE SELECT AN INTENSITY RANGE

------------------------------------------------------------------

configure the sensor for low intensities from 1nW/cm²...10µW/cm²

configure the sensor for medium intensities from 10µW/cm²...100mW/cm²

configure the sensor for high intensities from 100mW/cm²...10W/cm²

------------------------------------------------------------------

PLEASE SELECT A CONNECTOR

------------------------------------------------------------------

configure the sensor with a 2m shielded cable

configure the sensor with a male 5pin plug; a 2m cable is provided

configure the sensor to be submersible

---------------------------------------------------

please choose additional accessories here

---------------------------------------------------

Measurement window for certified UV sensors according to DVGW 294-3 and ÖNORM M5873
minimum order quantity 15 pieces

product picture

PT100 sensor integrated into the probe housing

Please select the housing, a spectral sensitivity and the desired measurement range for your digital UV sensor in the following section.

USB adapter box (DIGIBOX) for use with a PC, software for trend vizualisation and datalogging additional available for all digital UV sensors.

For information about optional calibration services, please visit our .

------------------------------------------------------------------

PLEASE SELECT A MECHANICAL DESIGN

------------------------------------------------------------------

Digital UV-Sensor, high resolution, wide dynamic range, CAN bus signal, incl. temperature measurement, temperature compensation

Product picture

Digital waterproof UV-Sensor for outdoor use, high resolution, wide dynamic range, CAN bus signal, incl. temperature measurement, temperature compensation

Product picture

Digital axis oriented in-chamber UV-Sensor, high resolution, wide dynamic range, CAN bus signal, incl. temperature measurement, temperature compensation

Product picture

Digital 10 bar water pressure proof UV-Sensor for low pressure lamps, high resolution, wide dynamic range, CAN bus signal, incl. temperature measurement, temperature compensation

Product picture

Digital UV-Sensor for DVGW certified water purifiers, high resolution, wide dynamic range, CAN bus signal, incl. temperature measurement, temperature compensation

Product picture

------------------------------------------------------------------

PLEASE SELECT A SPECTRAL SENSITIVITY

------------------------------------------------------------------

configure the sensor with an UV broadband SiC detector

spectral sensitivity

configure the sensor with an UVA-only SiC detector

spectral sensitivity

configure the sensor with an UVB-only/UV-Index SiC detector

spectral sensitivity

configure the sensor with an UVC-only SiC detector

spectral sensitivity

------------------------------------------------------------------

PLEASE SELECT AN INTENSITY RANGE

------------------------------------------------------------------

The sensor measures low UV radiations up to 1mW/cm² with a resolution of 10nW/cm².

The sensor measures medium UV intensities up to 50mW/cm² with a resolution of 500nW/cm².

The sensor measures high UV radiations up to 10W/cm² with a resolution of 100µW/cm².

CAN to USB converter box, up to 8 digital UV sensors can be connected.

Incl. PC software "DigiLog", shows actual values and trends of irradiation and temperature measurements.

product picture

Digital multi-channel UV Radiometer

• 100% touch-screen controlled
• Dosimetry and datalogging
• digital signal conversion (CAN bus)
• compliant with GLP and LIMS standard
• intuitive handling
• with customized spectral characteristics
• UVTOUCH sensor not included

 product picture           short overview

Digital UV Sensor for the UVTOUCH radiometer

• digital signal conversion (CAN bus)
• compliant with GLP and LIMS standard
• with customized spectral characteristics available

 product picture

The production of our UVLOG is discontinued.

UVLOG sensors with application specific characteristics (UV broadband, UVA, UVB, UVC, erythema or v(lambda)) are still available.

Re-calibration of the UVLOG and UVLOG sensors are possible.

UV-VIS-Spectrometer with Concave Grating

NIST traceable calibration

Different probes avaliable

PC Software

product picture

Miniature UV datalogger for long-time monitoring of moving goods, persons or animals, additional sensors e.g. temperature, pressure, rel. humidity, illuminance (VIS) 2.000.000 data records.

A sensor with application specific characteristics (UV broadband, UVA, UVB, UVC, erythema or v(lambda)) and a PC software is included.

product picture

Like UVMINILOG but smaller and less weight, also available as IP67 version, shorter battery lifetime.

product picture

4-channel datalogger, configurable display, operation with battery or power supply, DIN rail mountable, for use with all TOCON detectors, price without detector
product picture

Versatile industry measurement controller for control cabinet integration.

adjustable setpoints, relay output, condition visualization via multicolor-LED, possible inputs - photo current 4nA...4µA, 4...20mA, 0...20mA, 0...xV (x configurable up to 10), DIN rail mounting

product picture

Measuring and control module for monitoring and automation of irradiation processes.

Indication of radiation, dose and status information

Three programmable relays for automation of single- and multi-level irradiation processes.

Input for one probe with pre-amplification or one photodiode.

product picture

Like Sensor Monitor 5.0 but with USB and RS232 outputs for data transfer to a PLC or computer.

product picture

Like Sensor Monitor 5.0 but with two measuring inputs for simultaneous measurement/switching with two probes/photodiodes for measurement of two different radiations or at two different measurement points.

Various logic combinations of both signal inputs with the three relays.

product picture

Like Sensor Monitor 5.0 Double but with USB and RS232 outputs for data transfer to a PLC or computer.

product picture

Two-channel measurement and control module for control and automation of irradiation processes.

Tabletop unit incl. power supply

Visualization of radiation, dose and state information

Three programmable relays (banana sockets) for automation of single and multi stage irradiation processes.

USB/RS232 data output

product picture

Dual Channel Photodiode Amplifier

versatile, multi- configurable amplification of currents from pA range up to µA range. Well suited for experimental setup and small series.

product picture

versatile 2-channel current to voltage converting amplifier, one analog and one digital output

product picture

transmitter (current amplifier) with output current of 4-20mA to include photodiodes into an industrial 4-20 mA data bus

maximum photocurrent: 250µA

product picture

transmitter (current amplifier) with output current of 4-20mA to include photodiodes into an industrial 4-20 mA data bus

maximum photocurrent: 2,5µA

product picture

transmitter (current amplifier) with output current of 4-20mA to include photodiodes into an industrial 4-20 mA data bus

maximum photocurrent: 18nA

product picture

voltage amplifier, conversion of photocurrent into a 0-5V output signal

maximum photocurrent: 500µA

product picture

voltage amplifier, conversion of photocurrent into a 0-5V output signal

maximum photocurrent: 5µA

product picture

voltage amplifier, conversion of photocurrent into a 0-5V output signal

maximum photocurrent: 40nA

product picture

Reference Standard for all offered photodiode amplifiers with rugged shielded housing, cables, power supply and traceable calibration.

product picture

UV hand lamp with two selectable UV bulbs (UVA, UVB or UVC).
Rugged mechanical timer for defined irradiation time.
Applications: irradiation of biological and pharmaceutical samples, material inspection, fluorescence excitation, forensic and contamination analysis

product picture

Fixture for UV hand lamp LPL-01, height adjustable, scale for reproducible positioning

product picture

broadband photodiode (gallium-nitride) in TO18 housing

product picture

broadband UV photodiode (gallium nitride) in ultra compact 1608 SMD housing

product picture

broadband UV photodiode (gallium nitride) in ultra compact 1608 SMD housing

product picture

UVB/UVC photodiode (aluminium gallium nitride) in a TO18 housing

product picture

UVB/UVC photodiode (aluminium gallium nitride) in a 3528 SMD housing

product picture

UVC photodiode, only sensible in the UVC

product picture

36W UVA lamp

36W UVB Lamp

36W UVC-lamp

Electronic ballast to control the above offered 36W UV lamps, stepless regulation of the lamp power with a 0-10V input voltage.
