| 氮化鋁鎵紫外線二極體
UV photodiodes (GaN and AlGaN) |
About the material (Aluminium)Gallium
Nitride (Al)GaN
(Al)GaN is a new semiconductor material for visible blind UV
photodiodes. By modification of the Al – to - Ga
stoichiometry it is possible to produce photodiodes with
different spectral behaviour. This allows to offer
Photodiodes sensible for broad band UV (UVA+UVB+UVC), for
UVB-only and for UVC only without using a filter. |
|
|
AG38S / UVA+UVB+UVC |
- Broad Band UVA+UVB+UVC photodiode
- Active Area A = 0,076 mm2
- TO18 metal housing
- 10mW/cm2 peak radiation results a
current of approx. 700 nA
AG38S 詳細規格
|
|
|
|
AG38AS-SMD-S (GUVA-S20ED) / UVA |
- UVA selective photodiode
- Active Area A = 0,076 mm2
- Optimally suited for low-cost UV consumer
applications
- Intrinsicly unsensitive in the visible due
to the wide-bandgap semiconductor material GaN
- Small SMD package (1608)
- High speed and low noise
AG38AS-SMD-S (GUVA-S20ED) 詳細規格
|
|
|
|
AG32S / UVB+UVC |
- UVB sensitive photodiode
- Active Area A = 0,076 mm2
- TO18 metal housing
- 10mW/cm2 peak radiation results a
current of approx. 700 nA
AG32S 詳細規格
|
|
|
|
AG32S-SMD (GUVB-S10GD) / UVB/UVC photodiode
|
- UVB sensitive photodiode
- Active Area A = 0,076 mm2
- 3528 SMD housing with Si window
- 10mW/cm2 peak radiation results a
current of approx. 700 nA
AG32S-SMD (GUVB-S10GD) 詳細規格
|
|
|
|
AG28S / AlGaN |
- UVC sensitive photodiode
- Active Area A = 0,076 mm2
- TO18 metal housing
- 10mW/cm2 peak radiation results a
current of approx. 240 nA
AG28S 詳細規格
|
|
| |
| 紫外線燈泡 UV Bulbs |
|
Model (Datasheet)
|
Description
|
Applications |
|
PL-L Cleo Comp. 36W IV UVA
|
36W / UVA lamp |
- Suntanning/skin pigmentation
- Insect traps
- Photochemical processes
|
 |
|
PL-L 36W / 01 |
36W / UVB lamp |
- Phototherapy in dermatology (psoriasis, SUP)
- These lamps produce UV-B radiation which is harmful
to human skin and eyes. They are therefore only
available for medical and industrial applications
|
|
|
|
PL-L 36 W 4P |
36W / UVC lamp |
- Killing or inactivating bacteria, viruses and other
primitive organisms
- Air, water and surface disinfection in hospitals,
bacteriological research and pharmaceutical
environments, and food processing industries such as
dairies, breweries and bakeries
- Disinfection of drinking water, waste water,
swimming pools, air conditioning systems, cold storage
rooms, packing materials etc.
- Used in a variety of photochemical processes
|
|
|
|
HF-R 136 PLL 36W |
Flat,
lightweight high-frequency electronic regulating ballast to
control the above offered 36W UV lamps, stepless regulation
of the lamp power with a 0-10V input voltage. |
- 1-10V installations with daylight linking and/or
movement detection (for energy savings)
- 1-10V installations with remote control systems
(combining energy savings with comfort)
- Installations with emergency back-up, according to
IEC 60598-2-22
|
|
|
|
|
